oracle 11g主从配置

主数据库安装数据库软件和实例；
备库不用安装实例，只安装数据库软件

一、主备查询是否归档

ps:查看是否处于log模式,如果不是执行如下命令

SQL > archive log list;

修改归档模式，需要重启数据库

--干净的关闭数据库
SQL> shutdown immediate
--以mount模式启动
SQL> startup mount
--切换到归档模式
SQL> alter database archivelog;
--开启强制日志
SQL> alter database force logging;
--打开数据库
SQL> alter database open;
--查看归档
SQL> archive log list;
--查看是否为强制日志
SQL> select force_logging from v$database;


注意：show parameter log_archive_dest查看归档日志的存放位置。

二、配置监听

1、主数据库监听配置

cd /data1/oracle/app/product/11.2.0/dbhome_1/network/admin

vi listener.ora

SID_LIST_LISTENER =
  (SID_LIST =
    (SID_DESC =
      (SID_NAME = orcl)
      (ORACLE_HOME =  /data1/oracle/app/product/11.2.0/dbhome_1)
      (PROGRAM = extproc)
    )
    (SID_DESC =
      (SID_NAME = orcl)
      (GLOBAL_DBNAME = orcl)
      (ORACLE_HOME =  /data1/oracle/app/product/11.2.0/dbhome_1)
    )
  )

LISTENER =
  (DESCRIPTION_LIST =
    (DESCRIPTION =
      (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.57)(PORT = 1521))
      (ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC1521))
    )
  )
ADR_BASE_LISTENER = /data1/oracle/app

vi tnsnames.ora

ORCL =
  (DESCRIPTION =
    (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.57)(PORT = 1521))
    (CONNECT_DATA =
      (SERVER = DEDICATED)
      (SERVICE_NAME = orcl)
    )
  )

LISTENER_ORCL =
  (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.57)(PORT = 1521))

PRIMARY =
  (DESCRIPTION =
    (ADDRESS_LIST =
      (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.57)(PORT = 1521))
    )
    (CONNECT_DATA =
      (SERVER = DEDICATED)
      (SERVICE_NAME = orcl)
    )
  )

STANDBY =
  (DESCRIPTION =
    (ADDRESS_LIST =
      (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.51)(PORT = 1521))
    )
    (CONNECT_DATA =
      (SERVER = DEDICATED)
      (SERVICE_NAME = orcl)
    )
  )

备注：主数据库和从数据库 tnsnames.ora 内容一样

2、从数据库监听配置

cd /data1/oracle/app/product/11.2.0/dbhome_1/network/admin

vi listener.ora （ip不同）

SID_LIST_LISTENER =
  (SID_LIST =
    (SID_DESC =
      (SID_NAME = orcl)
      (ORACLE_HOME =  /data1/oracle/app/product/11.2.0/dbhome_1)
      (PROGRAM = extproc)
    )
    (SID_DESC =
      (SID_NAME = orcl)
      (GLOBAL_DBNAME = orcl)
      (ORACLE_HOME =  /data1/oracle/app/product/11.2.0/dbhome_1)
    )
  )

LISTENER =
  (DESCRIPTION_LIST =
    (DESCRIPTION =
      (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.51)(PORT = 1521))
      (ADDRESS = (PROTOCOL = IPC)(KEY = EXTPROC1521))
    )
  )
ADR_BASE_LISTENER = /data1/oracle/app

vi tnsnames.ora

ORCL =
  (DESCRIPTION =
    (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.51)(PORT = 1521))
    (CONNECT_DATA =
      (SERVER = DEDICATED)
      (SERVICE_NAME = orcl)
    )
  )

LISTENER_ORCL =
  (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.51)(PORT = 1521))

PRIMARY =
  (DESCRIPTION =
    (ADDRESS_LIST =
      (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.57)(PORT = 1521))
    )
    (CONNECT_DATA =
      (SERVER = DEDICATED)
      (SERVICE_NAME = orcl)
    )
  )

STANDBY =
  (DESCRIPTION =
    (ADDRESS_LIST =
      (ADDRESS = (PROTOCOL = TCP)(HOST = 192.168.1.51)(PORT = 1521))
    )
    (CONNECT_DATA =
      (SERVER = DEDICATED)
      (SERVICE_NAME = orcl)
    )
  )

3、主从监听链接测试

oracle 用户下执行(主从两库都执行)

lsnrctl stop
lsnrctl start
lsnrctl status
tnsping primary
tnsping standby
sqlplus sys/密码@primary as sysdba
sqlplus sys/密码@standby as sysdba

二、主数据库 PRIMARY 启动参数设置

cd /data1/oracle/app/product/11.2.0/dbhome_1/dbs

1、生成默认参数文件initorcl.ora

SQL> sqlplus / as sysdba

SQL> create pfile from spfile;

2、编辑initorcl.ora

添加参数
/data1/oracle/app/product/11.2.0/dbhome_1/dbs

*.DB_UNIQUE_NAME='primary'
*.LOG_ARCHIVE_CONFIG='DG_CONFIG=(primary, standby)'
*.LOG_ARCHIVE_DEST_1='LOCATION=/data1/oracle/app/oradata/archive/ VALID_FOR=(ALL_LOGFILES,ALL_ROLES) DB_UNIQUE_NAME=primary'
*.log_file_name_convert='/data1/oracle/app/oradata/orcl','/data1/oracle/app/oradata/orcl'
*.LOG_ARCHIVE_DEST_2='SERVICE=standby LGWR ASYNC VALID_FOR=(ONLINE_LOGFILES,PRIMARY_ROLE) DB_UNIQUE_NAME=standby'
*.LOG_ARCHIVE_DEST_STATE_1='ENABLE'
*.LOG_ARCHIVE_DEST_STATE_2='ENABLE'
*.LOG_ARCHIVE_FORMAT='%t_%s_%r.arc'
*.LOG_ARCHIVE_MAX_PROCESSES=5
*.FAL_SERVER='standby'
*.FAL_CLIENT='primary'
*.STANDBY_FILE_MANAGEMENT='AUTO'

archive 为创建目录

mkdir -p /data1/oracle/app/oradata/archive

3、主库使用这个编辑后的参数文件

SQL> sqlplus / as sysdba
SQL> shutdown immediate;
SQL> create spfile from pfile;
SQL> startup;

--- 查看使用的配置文件

SQL> show parameter pfile

4、创建standby 日志文件

standby的日志大小，必须跟online redo log的大小一样，组数要比redo log多一组。


--查看Redo和Standby Redo
SQL> select * from v$logfile;
--仅仅显示Online Redo，不显示Standby Redo
SQL> select * from v$log;
--新增一组大小为500M的Standby Redo，这里的group号不得与Online redo重复


alter database add standby logfile group  11 '/data1/oracle/app/oradata/orcl/standby11.log' size 50M;
alter database add standby logfile group  12 '/data1/oracle/app/oradata/orcl/standby12.log' size 50M;
alter database add standby logfile group  13 '/data1/oracle/app/oradata/orcl/standby13.log' size 50M;
alter database add standby logfile group  14 '/data1/oracle/app/oradata/orcl/standby14.log' size 50M;

5、主库参数文件和密码文件拷贝到从库

/data1/oracle/app/product/11.2.0/dbhome_1/dbs/initorcl.ora
/data1/oracle/app/product/11.2.0/dbhome_1/dbs/orapworcl

-- 传输到 相对应的 相同目录下，修改为Oracle 权限
chown oracle:oinstall initorcl.ora
chown oracle:oinstall orapworcl

三、从数据库dbstandby 配置

oracle 用户下操作
su - oracle

1、vi initorcl.ora参数文件

*.DB_UNIQUE_NAME='standby'
*.LOG_ARCHIVE_CONFIG='DG_CONFIG=( primary , standby)'
*.log_file_name_convert='/data1/oracle/app/oradata/orcl','/data1/oracle/app/oradata/orcl'
*.LOG_ARCHIVE_DEST_1='LOCATION=/data1/oracle/app/oradata/archive/ VALID_FOR=(ALL_LOGFILES,ALL_ROLES) DB_UNIQUE_NAME=standby'
*.LOG_ARCHIVE_DEST_2='SERVICE=primary LGWR ASYNC VALID_FOR=(ONLINE_LOGFILES,PRIMARY_ROLE) DB_UNIQUE_NAME=primary'
*.LOG_ARCHIVE_DEST_STATE_1='ENABLE'
*.LOG_ARCHIVE_DEST_STATE_2='ENABLE'
*.LOG_ARCHIVE_FORMAT='%t_%s_%r.arc'
*.LOG_ARCHIVE_MAX_PROCESSES=5
*.FAL_SERVER='primary'
*.FAL_CLIENT='standby'
*.STANDBY_FILE_MANAGEMENT='AUTO'

2、建立从库所需目录


cd /data1/oracle/app
mkdir -p oradata/orcl
mkdir -p oradata/archive
mkdir -p admin/orcl/adump
mkdir -p admin/orcl/dpdump
mkdir -p admin/orcl/pfile
mkdir -p flash_recovery_area/orcl

3、启动从库为nomount 模式

sql>create spfile from pfile;
sql>startup nomount;

四、RMAN 拷贝主库数据到从库

1、RMAN连接到目标数据库和辅助数据库

rman target sys/xxxx@PRIMARY auxiliary sys/xxxx@STANDBY

2、使用RMAN的duplicate命令进行复制，两边目录结构相同，需要添加nofilenamecheck参数不然会报错

duplicate target database for standby from active database nofilenamecheck;

3、复制成功后，备库自动被加载为mount模式，进入sqlplus查看

select status from v$instance;

4、在备库开启实时日志应用

SQL> alter database recover managed standby database using current logfile disconnect from session;

5、主备库角色状态查询

SQL> select switchover_status,database_role from v$database;
--主库显示：TO STANDBY/PRIMARY，如果显示SESSION ACTIVE表示还有活动的会话，需要关闭活动的会话再检查
--备库显示：NOT ALLOWED/PHYSICAL STANDBY
